PVC Insulated Multicore Flexible Control Cable Rated Voltage 300/500V Sheath PVC

Ask Lasest Price
Brand Name :	ZHUFENG
Model Number :	DJYPVP
Supply Ability :	50000 Kilometer/Kilometers per Month
Price :	$0.99/meters 1000-9999 meters

Add to Cart

Product Details
Company Profile

PVC Insulated Multicore Flexible Control Cable Rated Voltage 300/500V Sheath PVC

Product Description

DJYPVP cable wire characteristics

Digital cable( computer cable) is suitable for rated voltage 500V and below for high interference resistance of electronic computer and automatic connection cable. The insulation of the ground wire core of the cable is type K type B low density polyethylene with anti oxidation performance.

Polyethylene has high insulation resistance, good voltage resistance, small dielectric coefficient and the influence of medium loss temperature and variable frequency is also small, which can not only meet the requirements of transmission performance, but also ensure the service life of the cable.

In order to reduce mutual crosstalk and external interference between loops, the cable is shielded. Cable shielding requirements are based on different occasions respectively: pair combination shielding, pair composition of cable total shielding, pair combination after total shielding and other methods.

Rated voltage (U0/U):300/500V Long-term working temperature is 70℃.

Ambient temperature for laying should not be lower than -40℃ for fixed laying and -15℃ for non-fixed laying.

Minimum bending radius: no less than 6 times of cable diameter for unarmored layer, no less than 12 times of cable diameter for armored layer

PVC Insulated Multicore Flexible Control Cable Rated Voltage 300/500V Sheath PVC

The differences between DJYPVP cable and KVVP cable

1.The insulation levels are different. Comparatively speaking, the insulation level of the control cable is slightly higher. Control cable insulation is generally 450/750V. 2. computer cable relatively more emphasis on the shielding effect, anti-interference performance is stronger. Most of the use of sub - shielding + total shielding. 3. control cable mechanical strength is higher than computer cable, tensile resistance, especially strip steel armored. Suitable for outdoor laying or even buried laying. And computer cable mechanical strength is slightly weak, not tensile, generally only in the substation or cabinet indoor laying

Specification

Product name	PE insulated twisted-pair copper braided separate shield and total shield PVC sheathed digital cable	Insulation	PE
Model	DJYPVP	Temperature	70°C
Rated voltage	300/500V	Standard	Q/HHTZH002.4
Specification	1/1.5/2.5mm² 2-12 pair core	Sheath	PVC
Shield	copper braid	Armour	steel tape armoring
Application	Cables for electronic computers and automatic connections requiring high interference resistance	Conductor	high quality Oxygen-free copper

Pure Oxygen-Free Copper Conductor to Ensure Conductivity.

Environmentally-Friendly PVC Material with Excellent Insulation Performance, Scratch Resistance, Abrasion Resistance, Great Toughness.

Other productions

Company Profile

ZhuFeng Cable Daming Co.,Ltd. is a professional wire and cable manufacturer established in accordance with the modern enterprise system. It is located in Daming County Industrial Park,Handan City,Hebei Province. The company has more than 80 employees covering an area of 40,000 square meters, a building area of 25,000 square meters, fixed assets of 15 million yuan, dozens of existing production equipment, more than 30 sets of testing equipment and instruments, annual production capacity of hundreds of millions of yuan.

The company has passed the IS09001 international quality management system certification, and has obtained the industrial production license certificate and the national compulsory product CCC certification certificate.The products have passed the national testing center over the years,and the quality inspection departments of provinces and municipalities have passed the sampling inspection.

The main products produced by the company are: sheath wire,plastic copper wire, fire-fighting cable, fire-proof cable, power cable, control cable and other types of wire and cable.

With abundant manufacturing experience,strong technical force and complete testing equipment, we have provided high-quality products and services for many national key projects, and enjoyed high popularity and reputation among users. Products are widely used in power, construction, petrochemical, military, mechanical manufacturing, electronics, scientific research,communications and other fields. Best-selling in more than 30 provinces and municipalities throughout the country.

We sincerely welcome friends at home and abroad to cooperate with us and work together for a better future based on the principle of mutual benefit.

Production equipment

Our company has large-scale comprehensive wire and cable production workshop in China, advanced production equipment in the world,

many experts and skilled operators, professional technicians in product development, design and manufacture, and engineers and technicians in field technical services.

Testing equipment

The company has fornulated international market demand standards as the guide,high-quality products as the core, seientific and technological progress and technological innovation as the driving force, to achieve product diversification, production specialization and overall standardization of management as the goal. Everest cable will be built into an international high-tech processing and manufacturing enterprise.

Packing & Delivery

To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.

FAQ

Q: Can you send samples?
A: Of course, we can send samples to all parts of the world, our samples are free, but customers need to bear the courier costs.

Q: What product information do I need to provide?
A: You need to provide the grade, width, thickness, coating and the number of tons you need to purchase.

Q: What are the shipping ports?
A: Under normal circumstances, we ship from Shanghai, Tianjin, Qingdao, Ningbo ports, you can choose other ports according to your needs.

Q: About product prices?
A: Prices vary from period to period due to cyclical changes in the price of raw materials.

Q: What are the certifications for your products?
A: We have ISO 9001, SGS, EWC and other certifications.

Q: How long does your delivery time take?
A: In general, our delivery time is within 30-45 days, and may be delayed if the demand is extremely large or special
circumstances occur.

Q: Can I go to your factory to visit?
A: Of course, we welcome customers from all over the world to visit our factory. However, some of the plants are not open to the public.

Q: Does the product have quality inspection before loading?
A: Of course, all our products are strictly tested for quality before packaging, and unqualified products will be destroyed.

Q: How to pack the products?
A: The inner layer has a waterproof paper outer layer with iron packaging and is fixed with a fumigation wooden pallet. It can effectively protect products from corrosion during ocean transportation.

Q: What is your working time?
A: In general, our online service time is Beijing time: 8:00-22:00, after 22:00, we will reply to your inquiry during the next
working day.
